Melting and Casting
Steel and alloying metals are loaded into an electric arc furnace. Once in the furnace, the metal is heated to a specific temperature above its melting point, usually in excess of 2800°F.
Stainless Steel 317 Bars, Rods, Wires
- Home
- Products
- Bars, Rods, Wires
- Stainless Steel
- 317 / 317L
What are the key properties of Stainless Steel 317/317L Bars, Rods, and Wires?
Stainless Steel 317/317L Bars, Rods, and Wires exhibit a range of key properties and characteristics that make them highly desirable in various industries. These materials are known for their exceptional corrosion resistance, particularly in environments containing acids such as sulfuric acid and chlorides. This corrosion resistance is attributed to the high composition of molybdenum and chromium, which forms a protective oxide layer on the surface, preventing the material from deteriorating.
Table Of Content
- Manufacturing Process Of Stainless Steel 317 Bars
- Specification Of SS 317 Rods
- Stainless Steel 317 Wires Equivalent Grades
- Chemical Composition of SS 317 Bars
- Mechanical Properties of SS 317L Bars
- Types Of Stainless Steel 317 Bars, Rods, Wires
- Other Types Of Stainless Steel 317 Rods
- UNS S31700 Bars Price, Dimension, Weight
- SS 317 Rods Industrial Application
- Export & Supply Destination of SS 317L Wires
What common applications utilize Stainless Steel 317/317L Bars, Rods, and Wires?
Stainless Steel 317 Bars have extensive use in various applications across various industries. This material's exceptional corrosion resistance and high-temperature strength make it well-suited for chemical processing, petrochemical, and pharmaceutical applications. Stainless Steel 317 Bars are commonly employed to construct storage tanks, piping systems, and equipment for corrosive chemicals, acids, and solvents. Due to their resistance to chloride-induced pitting and crevice corrosion, these bars are extensively utilized in marine environments and offshore structures.
Stainless Steel 317L Rods are widely employed in several applications across diverse industries owing to their unique characteristics. One common application of Stainless Steel 317L Rods is in manufacturing heat exchangers and condensers, particularly in the chemical and petrochemical industries. These rods exhibit excellent corrosion resistance, making them suitable for handling aggressive chemicals and acidic environments. Another common application is in the pharmaceutical industry, where Stainless Steel 317L Rods are utilized to fabricate equipment and vessels that require high levels of cleanliness and corrosion resistance.
Due to their excellent properties, Stainless Steel 317 and 317L Wires have many common applications across multiple industries. One common application is in the electrical and electronics industry, where these wires are used for manufacturing heating elements, resistors, and other components that require high-temperature resistance and electrical conductivity. Another general application is in the automotive industry. Stainless Steel 317 and 317L Wires are utilized in exhaust systems, catalytic converters, and sensors due to their exceptional corrosion resistance and ability to withstand high temperatures.
Forming
Most cast steel is formed by hot rolling—the slab, bloom, or billet is heated and passed through large rollers, stretching out the steel into a longer, thinner form.
Heat treatment
Heat treatment strengthens rolled stainless steel by recrystallizing the deformed microstructure. Most stainless steel is heat treated by annealing.
Descaling
A rolled piece of stainless steel acquires a layer of oxidized “mill scale,” which needs to be washed away to restore a shiny surface finish.
Cutting or Machining
Stainless steel is cut to a specified shape and size. The stainless steel can be sheared with circular knives, sawed with high-speed blades, or blanked with punches.
Packaging and Delivery
To reach their destination in pristine condition, we employ careful packaging techniques.
| SS Bar Wire Standard | ASTM A276 / A479, ASME SA276 / A479 ASTM A580 ASME SA580 / ASTM A313 ASME SA313, AMS 5514 |
| Stainless Steel Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Stainless Steel Round bar size | Diameter: 3-~800mm |
| Stainless Steel Hex Bar size | 2-100mm A/F |
| SS Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Stainless Steel Square bar size | 4 to 100mm |
| SS Wire Length | Cut Lengths: 0.125" to 72" No Limit on Spooled Lengths |
| SS Wires Diameter | 0.0004" to 0.040" 10 microns to 1.0 mm Other Sizes on Request |
| Wire Condition | M, Y, 1/2Hard |
| SS Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| SS Rectangular Bars Section | 3.0 to 12.0mm thickness |
| ASTM A276 Type Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| SS Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Stainless Steel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| SS Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| ASTM A276 SS Type Hollow Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| T-Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Rolled Stainless Steel Flat Bars Condition | Hardened & tempered, annealed |
| ASTM A276 Type Cold Rolled Bar Technique | Stainless Steel Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Stainless Steel Rounds Bar Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Wire available in form of | Flat, Coil, mesh, Knitted wire mesh, spring, stranded and twisted |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317 | 1.4449 | S31700 | SUS 317 | - |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 - 20.00 | 3.00 - 4.00 | 11.00 - 15.00 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 - 20.00 | 3.00 - 4.00 | 11.00 - 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
317L SS Rods
317 SS Wire Rope
317L Stainless Steel Square Bars
317 Stainless Steel Wire Mesh
317 Stainless Steel Hexagonal Bar
317 Stainless Steel Forged Bar
317L Stainless Steel Hot Rolled Bar
Stainless Steel 317 Spool Wire
UNS S31700 Cold Rolled Bar
Stainless Steel 317 Coil Wire
SS 317 Flat Bar
- 1.4449 Threaded Bars
- 317 Stainless Steel Hot Rolled Bar
- Stainless Steel 317L Square Bars
- SS 317L Coil Wire
- 317 Stainless Steel Wire Rope
- Stainless Steel 317L Hot Rolled Steel Bars
- SS 317L Round Bar
- Stainless Steel 317 Bright Round Bars
- UNS S31700 Wires
- ASTM A580 317 Stainless Steel Wire Bobbin
- Stainless Steel 317 Polished Bar
- Stainless Steel 317L Wires
- SS 317 Spring Steel Wire
- SS 317 Precision Round Bars
- 317L Stainless Steel Cold Drawn Flat Bars
- Stainless Steel 317 12mm Bar
- UNS S31703 Wire Spool
- Stainless Steel 317 Reel Wire
- 1.4438 Spring Wire
- 317 Stainless Steel Wire Mesh
- SS 317L Rectangular Rod
- ASTM A276 SS 317 Forged Bar
- ASME SA276 317L Stainless Steel Hollow Bar
- SS 317L Round Rod
- 317 Stainless Steel Ribbon Wires
- 317L Stainless Steel Spool Wire
- Stainless Steel 317 Round Bar
- 317 Stainless Steel Hex Bar
- SS 317 T-Bar
- Stainless Steel 317 Rod
