What is Stainless Steel 316Ti?
Stainless Steel
316Ti is a titanium-stabilized version of Stainless Steel 316. It is an
austenitic stainless steel alloy that contains increased levels of titanium. The addition of
titanium provides improved resistance to sensitization and intergranular corrosion, making
it suitable for high-temperature applications.
What are the advantages of using Stainless Steel 316Ti fittings?
There are several advantages of using Stainless Steel 316Ti fittings.
Firstly, they offer excellent resistance to corrosion, including resistance to pitting and
crevice corrosion. Secondly, the titanium stabilization improves resistance to sensitization
and maintains structural integrity at elevated temperatures. Additionally, Stainless Steel
316Ti fittings have good weldability and formability.
What are the common applications of Stainless Steel 316Ti fittings?
Stainless Steel 316Ti fittings are commonly used in various industries and
applications. Some common applications include chemical processing, petrochemical,
pharmaceuticals, food and beverage processing, heat exchangers, exhaust systems, and
high-temperature environments where resistance to corrosion and sensitization is required.
What are the available types and sizes of Stainless Steel 316Ti fittings?
Stainless Steel 316Ti fittings are available in a variety of types and sizes to accommodate
different needs. Common types include elbows, tees, reducers, couplings, caps, and stub
ends. The sizes range from small diameters such as 1/2 inch to larger sizes such as 24
inches, with varying wall thicknesses and schedules depending on the specific application
and manufacturer.
How does Stainless Steel 316Ti compare to other stainless steel grades for buttweld
fittings?
Stainless Steel 316Ti offers specific advantages compared to other stainless steel grades
for buttweld fittings. Its titanium stabilization provides improved resistance to
sensitization and intergranular corrosion, particularly in high-temperature environments.
When compared to other stainless steel grades such as 316L, 316Ti exhibits enhanced
resistance to corrosion and maintains its mechanical properties at elevated temperatures.
Manufacturing Process Of Stainless Steel 316Ti Buttweld Fittings
Raw Material Selection
The manufacturing process of buttweld fittings begins with the careful
selection of raw materials.
Cutting and Shaping
Once the raw materials are selected, they undergo a precise cutting and
shaping process.
Heating and Forming
Heating the materials to a specific temperature ensures they become
malleable, facilitating the shaping process.
Welding and Joining
These processes ensure secure and leak-proof connections, enhancing the
reliability and longevity.
Finishing and Quality Control
After this the buttweld fittings undergo comprehensive finishing and
quality control procedures.
Packaging and Delivery
To reach their destination in pristine condition, we employ careful
packaging techniques.
Specification Of SS 316Ti Butt Weld Fittings
Specifications |
ASTM A403 / ASME SA403 |
Size |
Seamless Butt Weld Fittings: 1/2" - 10"
Welded Butt Weld Fittings: 1/2" - 48" |
Thickness |
SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH
140, SCH 160, XXS available with NACE MR 01-75 |
Type |
DN15-DN1200 |
Dimensions |
ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
Bending Radius |
R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom MSS Sp-43 Stainless Steel Pipe
Fitting |
Size Range |
½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A403
Stainless Steel Buttweld Fitting |
Elbows |
Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D,
3D, 4D, 5D, 6D, 7D-40D .
Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311
JISB2312 JISB2313, BS, GB, ISO |
Connection |
Welding |
Manufacturing process |
Forge, Cast, Push, Press, etc. |
Key markets and industries |
Bitumen upgraders.
Heavy oil refineries.
Petrochemicals and acids.
Nuclear power (mostly seamless).
|
Test Certificates |
EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc |
Specialized manufacturer of |
90º Elbows, 45º Elbows, Tees, Crosses, Reducers, Pipe Cap, Stub End, Pipe
Bend |
We provide Material Test Certificates (MTC) as per EN 10204 3.1
and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 |
Stainless Steel 316Ti Buttweld Fittings Equivalent Grades
STANDARD |
UNS |
WNR. |
AFNOR |
EN |
JIS |
BS |
GOST |
SS 316Ti |
S31635 |
1.4571 |
Z2 NCDU 25-20 |
X1NiCrMoCu25-20-5 |
SUS 316Ti |
904S13 |
- |
Chemical Composition of SS 316Ti Buttweld Fittings
|
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
316TI(S31635) |
- |
- |
- |
- |
- |
16.0 |
2.00 |
10.0 |
- |
0.08 |
2 |
0.75 |
0.045 |
0.03 |
18.0 |
3.00 |
14.0 |
0.1 |
Mechanical Properties of SS 316Ti Buttweld Fittings
Grade |
Tensile Strength
ksi (min)
|
Yield Strength
0.2% ksi (min)
|
Elongation % |
Hardness (Brinell) MAX |
Hardness
(Rockwell B) MAX
|
316TI(S31635) |
515(Mpa) |
205(Mpa) |
35 |
205 |
75 |
Types Of Stainless Steel 316Ti Welded Fittings
316Ti Stainless Steel 90 Degree Elbow
316Ti SS Long Radius Elbow
316Ti Stainless Steel Short Radius Elbow
316Ti Stainless Steel Concentric Reducer
316Ti Stainless Steel Eccentric Reducer
WP316Ti Stainless Steel Pipe Bend
316Ti Stainless Steel Tee
Stainless Steel 316Ti Cross
Stainless Steel 316Ti Stub End
Stainless Steel 316Ti Pipe Cap
Other Types Of Stainless Steel 316Ti Seamless Fittings
- Stainless Steel 316Ti Stub End
- SS 316Ti Schedule 10 Two Joint Pipe Fittings
- 316Ti Stainless Steel 90° Weldable SR Elbow
- UNS S31635 Welded Fittings
- SS 316Ti Schedule 40 180° LR Return Bend
- Stainless Steel 316Ti Elbow
- 316Ti Stainless Steel Reducer
- SS 316Ti Seamless Pipe Elbow
- UNS S31635 Buttweld Fittings
- UNS S31635 Buttweld Pipe Fittings
- ASTM A403 WP316Ti Stainless Steel 45 Degree Elbow
- 1.4571 Seamless Fittings
- Stainless Steel 316Ti Seamless Pipe Bend
- 2 inch 316Ti Stainless Steel Pipe Fittings
- 316Ti Stainless Steel Pipe Fittings
- 1.4571 Equal Cross
- 316Ti Stainless Steel Weldable 3D Elbow
- SS 316Ti Schedule 40 Pipe Reducer
- Stainless Steel 316Ti SR Elbow
- ASTM A403 WP316Ti 45° Long Radius Elbow
- ASME B16.9 Stainless Steel 316Ti 1D Elbow
- ASME SA403 WP316Ti Stainless Steel Buttweld Cap
- SS 316Ti Sch 10 Lateral Tee
- 316Ti Stainless Steel End Pipe Cap
- Stainless Steel 316Ti U Bend
- 316Ti Stainless Steel 180 Degree Elbow
- 316Ti Stainless Steel Lap Joint Stub End
- Stainless Steel 316Ti Pipe End Cap
- Stainless Steel 316Ti Reducing Tee
- MSS-SP-75 SS 316Ti Buttweld Pipe Fittings
UNS S31635 Buttweld Fittings Price, Dimension, Weight
