Melting and Casting
Steel and alloying metals are loaded into an electric arc furnace. Once in the furnace, the metal is heated to a specific temperature above its melting point, usually in excess of 2800°F.
Alloy Steel F9 Bars, Rods, Wires
What is Alloy Steel F9, and what are its key properties?
Alloy Steel F9 is a steel specifically formulated to exhibit enhanced mechanical properties and exceptional resistance to corrosion and high-temperature environments. This alloy is primarily composed of iron and significant amounts of chromium, molybdenum, and vanadium. Adding these alloying elements imparts several key properties to Alloy Steel F9. It offers excellent tensile strength, capable of withstanding heavy loads and stress without deformation. Alloy Steel Grade 9 also exhibits remarkable hardness, providing resistance against wear and abrasion.
Table Of Content
- Manufacturing Process Of Alloy Steel F9 Bars
- Specification Of Alloy Steel F9 Rods
- Alloy Steel F9 Wires Equivalent Grades
- Chemical Composition of Alloy Steel F9 Bars
- Mechanical Properties of Alloy Steel F9 Bars
- Types Of Alloy Steel F9 Bars, Rods, Wires
- Other Types Of Alloy Steel F9 Rods
- UNS K90941 Bars Price, Dimension, Weight
- Alloy Steel F9 Rods Industrial Application
- Export & Supply Destination of Alloy Steel F9 Wires
What manufacturing standards and specifications should be considered when sourcing Alloy Steel F9 bars, rods, and wires?
When sourcing Alloy Steel Grade 9 bars, it is essential to consider specific manufacturing standards and specifications to ensure the quality and suitability of the product. One crucial standard to look for is the ASTM International standard designation A182, which provides guidelines for manufacturing forged or rolled alloy and stainless steel pipe flanges, fittings, valves, and parts. Under this standard, Alloy Steel Grade 9 bars should adhere to the specific chemical composition requirements, mechanical properties, and heat treatment processes outlined.
When sourcing Alloy Steel F9 rods, it is important to consider specific manufacturing standards and specifications to ensure the quality and suitability of the product. One key standard to consider is the ASTM International standard designation A479, which provides guidelines for producing stainless steel bars and shapes for various applications. Although Alloy Steel Grade 9 is not stainless steel, this standard is often referenced for alloy steel rods due to its comprehensive guidelines. It outlines requirements for the chemical composition, mechanical properties, heat treatment, and dimensions of the rods.
When sourcing Alloy Steel F9 wires, it stands vital to consider specific manufacturing standards and specifications to ensure the quality and suitability of the product. One critical standard to look for is the ASTM International standard designation A29/A29M, which provides guidelines for the general requirements for steel bars, carbon, alloy, hot-wrought, and cold-finished. Although this standard primarily focuses on steel bars, it is often referenced for alloy steel wires due to its comprehensive guidelines on chemical composition, mechanical properties, and heat treatment processes.
Forming
Most cast steel is formed by hot rolling—the slab, bloom, or billet is heated and passed through large rollers, stretching out the steel into a longer, thinner form.
Heat treatment
Heat treatment strengthens rolled stainless steel by recrystallizing the deformed microstructure. Most stainless steel is heat treated by annealing.
Descaling
A rolled piece of stainless steel acquires a layer of oxidized “mill scale,” which needs to be washed away to restore a shiny surface finish.
Cutting or Machining
Stainless steel is cut to a specified shape and size. The stainless steel can be sheared with circular knives, sawed with high-speed blades, or blanked with punches.
Packaging and Delivery
To reach their destination in pristine condition, we employ careful packaging techniques.
| Standard | ASTM A182 / ASME SA182 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Wire Length | Cut Lengths: 0.125" to 72" No Limit on Spooled Lengths |
| Wires Diameter | 0.0004" to 0.040" 10 microns to 1.0 mm Other Sizes on Request |
| Wire Condition | M, Y, 1/2Hard |
| Angle Bar Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Hollow Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| T-Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Wire available in form of | Flat, Coil, mesh, Knitted wire mesh, spring, stranded and twisted |
| STANDARD | WERKSTOFF NR. | UNS |
| Alloy Steel F9 | 1.7386 | K90941 |
| Grade | C | Mn | Si | Mo | Cr | P | Others |
| Alloy Steel F9 | 0.15 Max | 0.30 - 0.60 | 0.50 - 1.00 | 0.90 - 1.10 | 8.0 - 10.0 | 0.030 | - |
| Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min |
| 415 | 30 | 205 |
Chrome Moly F9 Rods
Alloy Steel F9 Wire Rope
CrMo F9 Square Bars
F9 Alloy Steel Wire Mesh
Alloy Steel F9 Hexagonal Bar
Alloy Steel F9 Forged Bar
High Pressure Steel F9 Hot Rolled Bar
Alloy Steel F9 Spool Wire
UNS K90941 Cold Rolled Bar
Chrome Moly F9 Coil Wire
Alloy Steel F9 Flat Bar
- Alloy Steel F9 Precision Round Bars
- Chrome Moly F9 Square Bars
- Alloy Steel F9 Round Bar
- Chrome Moly F9 Bright Round Bars
- Alloy Steel F9 Wire Rope
- UNS K90941 Wires
- Alloy Steel F9 Wires
- High Pressure Steel F9 Polished Bar
- F9 Alloy Steel Spring Hard Wire
- CrMo F9 Hot Rolled Steel Bars
- Chrome Moly F9 Coil Wire
- Chrome Moly F9 Hot Rolled Bar
- ASTM A182 Alloy Steel F9 Wire Bobbin
- 1.7386 Threaded Bars
- CrMo F9 Cold Drawn Flat Bars
- UNS K90941 Wire Spool
- 1.7386 Spring Wire
- ASME SA182 Alloy Steel F9 Hollow Bar
- CrMo F9 Wire Mesh
- F9 Alloy Steel Soft Wire
- Alloy Steel F9 Rod
- Chrome Moly F9 Round Rod
- ASTM A182 Alloy Steel F9 Forged Bar
- F9 Alloy Steel Round Bar
- Alloy Steel F9 Rectangular Rod
- High Pressure Steel F9 12mm Bar
- CrMo F9 Spool Wire
- Alloy Steel F9 ¼ Hard Wire
- Chrome Moly F9 T-Bar
- Alloy Steel F9 Hex Bar
Ask Free Sample of Alloy Steel F9 Bars, Rods, Wires Please Call On +91 9594327775 Or Mail Us On [email protected]
