Stainless Steel 316 Fasteners

Stainless Steel 316 Fasteners

What is the difference between Stainless Steel 316 and 316L fasteners?

Stainless Steel, 316, and 316L fasteners have slight differences in their composition, resulting in variations in their mechanical and chemical properties. Both alloys are part of the austenitic stainless steel family and contain chromium, nickel, and molybdenum. However, the "L" in 316L stands for "low carbon," indicating a lower carbon content than 316. That reduced carbon content helps enhance the weldability of 316L, making it suitable for welding or extensive fabrication applications.

The lower carbon content in 316L also improves resistance against sensitization, a process in which chromium carbide precipitation occurs at grain boundaries, reducing corrosion resistance. By minimizing this sensitization effect, 316L offers superior corrosion resistance compared to 316 in environments where the material is exposed to high temperatures, such as in welding operations.

While both alloys exhibit excellent corrosion resistance in a wide range of environments, the lower carbon content of 316L grants it enhanced resistance to intergranular corrosion, making it well-suited for applications in corrosive environments such as marine environments or chemical processing plants.

What applications are Stainless Steel 316 fasteners commonly used in?

Stainless Steel 316 fasteners find wide application across various industries and sectors due to their excellent mechanical properties and superior corrosion resistance. One common application is in the marine industry, where the fasteners are exposed to harsh saltwater environments. The high corrosion resistance of Stainless Steel 316 makes it ideal for use in boat building, offshore structures, and marine equipment.

316 Stainless Steel Fasteners

The chemical and petrochemical industries also extensively use Stainless Steel 316 fasteners. These fasteners resist corrosion from various chemicals and acids, making them suitable for equipment and structures exposed to corrosive substances. In addition, their high-temperature resistance makes them suitable for applications involving elevated temperatures.

The food and beverage industry is another major sector that relies on Stainless Steel 316 fasteners. These fasteners are favoured due to their hygienic properties, resistance to corrosion from food acids, and ease of cleaning. They are commonly used in food processing machinery, commercial kitchens, and storage tanks.

Manufacturing Process Of Stainless Steel 316 Fasteners

SS 316 Bolts and Nuts Specification

Standard ASTM F593, F594, A193, A194 / ASME SF593, F594, SA193, SA194
Bolt / Screw Size M3 – M56 | 3/6″ to 2″ | Custom Sizes
Nuts Size M3 – M56 | 3/6″ to 2″ | Custom Sizes
Washers Size M3 – M56 | 3/6″ to 2″ | Custom Sizes
Machine Screws Size M1.6 – M12
Self Tapping Screw Size No.2 – No. 14
Length 3 mm to 200 mm
Threads UNF, BSW, BSF, METRIC, UNC, or as required
Fasteners
  • DIN : DIN 934, DIN 931, DIN 970, DIN 933
  • UTS : UNEF, NPT, UNC, UNS, UNF, NPTF
  • ISO : JIS standards, ISO 4033, ISO 4032,
  • ANSI – American National Standards Institute
  • ASME B18.5
  • ANSI B 28.2.4 1M
  • as per defined in ASME B16.5 standard Stud Bolt length
  • ANSI B 18.2.4 2M
  • as per defined in ASME B18.2.2 Hex nuts
Dimensions DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3
Threads Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically
Test Certificate as per EN 10204 / 3.1 Manufacturer Test Certificate
Additional Certifications PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified
Production Process M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC
Types Bolts, Nuts, Stud Bolts, Washers, Threaded Rod, Anchor Fasteners, Eye Bolt, Stud, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, Hexagon Castle Nuts, Hexagon Domed Cap Bolts, Hexagon Thin Nuts etc.

Stainless Steel 316 Fasteners Equivalent Grades

STANDARD UNS WNR. AFNOR EN JIS BS GOST
SS 316 S31600 1.4401 / 1.4436 Z7CND17‐11‐02 X5CrNiMo17-12-2 / X3CrNiMo17-13-3 SUS 316 316S31 / 316S33 -
SS 316L S31603 1.4404 / 1.4435 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2

Chemical Composition of SS 316L Fasteners

C Mn Si P S Cr Mo Ni N
316
(S31600)
0.08
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max
316L
(S31603)
0.03
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max

Mechanical Properties of SS 316 Fasteners

Grade Tensile Strength
ksi (min)
Yield Strength
0.2% ksi (min)
Elongation % Hardness (Brinell) MAX Hardness
(Rockwell B) MAX
316 (S31600) 75 30 40 217 95
316L (S31603) 70 25 40 217 95

Types Of Stainless Steel 316L Fasteners

316 SS Nuts

316 SS Nuts

316L SS Bolts

316L SS Bolts

316L Stainless Steel Screw

316L SS Screw

316 Stainless Steel Washers

316 Stainless Steel Washers

316 Stainless Steel Stud Bolt

316 Stainless Steel Stud Bolt

316L Stainless Steel Anchor Bolts

316L Stainless Steel Anchor Bolts

SS 316L Threaded Rod

SS 316L Threaded Rod

316 Stainless Steel Heavy Hex Bolts

316 Stainless Steel Heavy Hex Bolts

Stainless Steel 316 Hex Nuts

Stainless Steel 316 Hex Nuts

Other Types Of Stainless Steel 316 Fasteners

  • 316 Stainless Steel Machine Screws
  • 1.4401 Fasteners
  • ASTM F593 316 Stainless Steel Washers
  • 316 Stainless Steel Square Nuts
  • 316 Stainless Steel Fasteners
  • Stainless Steel 316 Nuts
  • UNS S31600 Fasteners
  • UNS S31603 Fasteners
  • 316L Stainless Steel Hex Head Bolts
  • Stainless Steel 316 Nut Bolt
  • Stainless Steel 316 Fasteners
  • 316 Stainless Steel U Bolts
  • UNS S31600 Fasteners
  • Stainless Steel 316 Bolts
  • 316 Stainless Steel Bolts and Nuts
  • 316 Stainless Steel Heavy Hex Nuts
  • 316 Stainless Steel Wing Nuts
  • ASTM F594 SS 316 Coupling Nuts
  • Stainless Steel 316 Industrial Fasteners
  • 1.4404 Nuts And Bolts
  • 316 Stainless Steel Double Ended Studs
  • SS 316L Self Locking Nuts
  • SS 316 Ogee Washer
  • Stainless Steel 316L Allen Cap Screw
  • Stainless Steel 316 U Bolts
  • 316L Stainless Steel Hex Bolt
  • SS 316 Spring Washer
  • 316L Stainless Steel Plain Washer
  • 316 Stainless Steel Screw
  • Stainless Steel 316 Flat Washer
